Chevrolet Sonic Repair Manual: Dome Lamp Bezel Replacement



Dome Lamp Bezel Replacement

Callout

Component Name

1

Dome Lamp Bezel Cover

Procedures

  1. Grasp the bezel cover and pull downward to remove from the lamp assembly.
  2. Disconnect the electrical connections, as necessary.

2

Dome Lamp Bezel Fasteners (Qty:?€‰2)

Caution:

Refer to Fastener Caution.

3

Dome Lamp Bezel

Procedures

  1. Pull assembly downward to remove.
  2. Disconnect the electrical connections.
