Callout |
Component Name |
---|---|
Preliminary Procedure
Remove the front side door widow switch bezel. Refer to Front Side Door Window Switch Bezel Replacement. |
|
1 |
Front Side Door Window Switch Assembly Procedure
|
Secondary Air Injection Pump Pipe Replacement
Secondary Air Injection Pump Pipe Replacement
Callout
Component Name
1
Hose Retainer (QTY:2)
Note: Squeeze the retainer on opposite sides to release.
2
Secondary Air Injection ...
Camshaft Timing Chain Adjustment
Special Tools
EN-952 Fixing Pin
EN-953–A Fixing Tool
EN-49977?E00 Fixation Sensor Discs
For equivalent regional tools, refer to Special Tools.
Remove the ignition coil. Refer to Ignition Coil Replacement.
Remove the camshaft cover. Refer to Camshaft Cover Replacement.
Remove ...
3-5-Reverse and 4-5-6 Clutch Housing Disassemble (6T30/40/45/50 - Gen 2)
Table 1:
Turbine Shaft, Reluctor Wheel and Piston Removal
Table 2:
4?? Clutch Plate Removal
Table 3:
4?? Clutch Piston Removal
Table 4:
Reluctor Wheel and Piston Removal
Table 5:
3? Reverse Clutch Plate Removal
Turbine Shaft, Re ...
