Callout |
Component Name |
---|---|
Preliminary Procedures
|
|
1 |
Instrument Panel Insulator |
Radiator Grille Bumper Replacement
Radiator Grille Bumper Replacement
Callout
Component Name
Preliminary Procedure
Remove the front bumper fascia. Refer to Front Bumper Fascia Replacement.
1
Radiator Grille Bumper Screw (Qty:?ۉ ...
Engine Mount Bracket Replacement
Engine Mount Bracket Replacement
Callout
Component Name
Preliminary Procedure
Remove the engine mount. Refer to Engine Mount Replacement.
1
Engine Mount Bracket Bolt (Qty: 3)
Cau ...
Turbocharger Assemble
Caution: Refer to Fastener Caution.
Install the NEW quick fitting connector (2) and a NEW seal ring (1) to the
turbocharger and tighten to 20 Y (15 lb ft).
Inspect the turbocharger coolant pipes for ridges and damage.
Install the tur ...
