Front Floor Console Extension Replacement - Left Side

Callout

Component Name

1

Front Floor Console Extension Push-In Retainer

2

Front Floor Console Extension

Procedure

Use a flat bladed plastic trim tool in order to release the retainers securing the extension to the console assembly.
