WARNING
Washer antifreeze solutions are toxic. Always store them in labeled containers and keep them away from children and animals.
Maintain the washer fluid level in your Nissan Armada by checking it periodically and refilling as needed, especially when the low washer fluid warning indicator appears.
To refill, open the reservoir cap and carefully pour washer fluid into the designated tank.
For improved cleaning performance, especially in colder climates, add a washer solvent or antifreeze solution. Always follow the manufacturer’s recommended mixing ratios.
During winter or heavy-use conditions, your Nissan Armada may require more frequent washer fluid refills.
For optimal results, use Genuine NISSAN Windshield Washer Concentrate Cleaner & Antifreeze or an equivalent product designed for automotive use.
CAUTION
Some alcohol-based concentrates may stain exterior parts such as the grille if spilled during filling.
Do not mix solutions directly inside the washer tank.
Proper maintenance of both brake fluid and washer fluid systems is essential for ensuring the safety, visibility, and overall performance of your Nissan Armada.
Brake fluid
BatteryIgnition Positions
The ignition switch has four different positions.
To shift out of P (Park), the ignition must be in ON/RUN and the regular brake
pedal applied.
1 (STOPPING THE ENGINE/LOCK/ OFF): When the vehicle is stopped, turn the ignition
switch to LOCK/ OFF to turn the engine off.
This position locks t ...
Hood Insulator Replacement
Hood Insulator Replacement
Callout
Component Name
1
Hood Insulator Plastic Retainer (Qty:?€‰6)
2
Hood Insulator
Procedure
Ensure the 3 integral tabs are secured to the hood.
...
Front Opening Upper Cover Replacement
Front Opening Upper Cover Replacement
Callout
Component Name
1
Radiator Opening Upper Cover Screw (Qty:?€‰10)
Caution: Refer to Fastener Caution.
2
Radiator Opening Upper Cove ...
