Chevrolet Sonic Repair Manual: Air Cleaner Outlet Duct Replacement



Air Cleaner Outlet Duct Replacement

Callout

Component Name

1

Air Cleaner Outlet Duct Clamp

2

Air Cleaner Outlet Duct Clamp

3

Air Cleaner Outlet Duct

Tip:

Air cleaner outlet front duct and air cleaner outlet rear duct are one part.
